Phoenix Battery Price in Pakistan Today (Tubular, UPS & Car)
Compare verified dealer prices for Phoenix Tubular (TX Series), Deep Cycle UPS (UGS Series), and Automotive Maintenance-Free batteries across Lahore, Karachi, and Islamabad.
Phoenix batteries, manufactured by Century Paper & Board Mills Ltd, are among Pakistan’s most preferred battery brands for domestic UPS inverters and commercial solar energy setups. Known particularly for their deep-discharge TX Series Tall Tubular batteries, Phoenix models deliver outstanding cycle life during extended summer load-shedding. Below is the complete price list organized by battery series and application.
1. Phoenix Tubular Battery Price (Solar & Long Backup UPS)
Tall tubular technology features gauntlet tubular plates that resist active material shedding, making them ideal for hybrid solar inverters and 8–12 hour daily backup:
| Phoenix Tubular Model | Price Range (PKR) |
|---|---|
| Phoenix TX 1000Tubular Deep Cycle • 85 Ah • Small UPS Setup | Rs. 28,500 – 30,500 |
| Phoenix TX 1400Tubular Deep Cycle • 120 Ah • 12V 1kVA Inverter | Rs. 35,000 – 37,500 |
| Phoenix TX 1600Tubular Deep Cycle • 140 Ah • Medium Backup Setup | Rs. 39,000 – 42,000 |
| Phoenix TX 1800Tubular Deep Cycle • 165 Ah • Standard Solar Choice | Rs. 46,000 – 48,500 |
| Phoenix TX 2000Tubular Deep Cycle • 185 Ah • Heavy 1.5–3kVA Inverter | Rs. 51,000 – 54,000 |
| Phoenix TX 2500Tubular Deep Cycle • 215 Ah • Long Backup Solar System | Rs. 58,000 – 62,000 |
| Phoenix TX 3000Tubular Deep Cycle • 240 Ah • High Capacity Commercial Setup | Rs. 66,000 – 70,000 |
2. Phoenix UGS & XP Series Battery Price (Standard UPS / Inverter)
Standard lead-acid flat plate batteries designed for cost-effective household UPS systems:
| Phoenix UPS Model & Plates | Price Range (PKR) |
|---|---|
| Phoenix UGS 11090 Ah • 15 Plates • Economy Home UPS | Rs. 24,000 – 26,000 |
| Phoenix UGS 135110 Ah • 19 Plates • Standard 2-Fan UPS Setup | Rs. 29,500 – 32,000 |
| Phoenix UGS 175140 Ah • 23 Plates • Most Popular Medium UPS Model | Rs. 38,000 – 41,000 |
| Phoenix UGS 200155 Ah • 27 Plates • Heavy Domestic UPS Battery | Rs. 44,000 – 48,000 |
| Phoenix UGS 210160 Ah • 29 Plates • High Cranking & Deep Discharge | Rs. 47,500 – 52,000 |
| Phoenix XP 200150 Ah • Heavy Duty Flat Plate Inverter Battery | Rs. 43,000 – 46,500 |
3. Phoenix Automotive & Car Battery Price
| Vehicle Type & Phoenix Model | Price Range (PKR) |
|---|---|
| Phoenix XP 40 (NS40ZL)32 Ah • Suzuki Alto, Cultus, WagonR, Mehran | Rs. 8,200 – 9,000 |
| Phoenix XP 50 (NS60)40 Ah • Honda City, Suzuki Swift, Toyota Yaris | Rs. 10,500 – 11,500 |
| Phoenix XP 65 (N50)50 Ah • Toyota Corolla, Honda Civic, BR-V | Rs. 12,800 – 13,800 |
| Phoenix XP 85 (N70)65 Ah • SUVs, Commercial Vans, Hilux, Fortuner | Rs. 16,500 – 18,000 |
| Phoenix XP 135 (N100)95 Ah • Heavy Transport, Coaster, Truck & Tractor | Rs. 24,000 – 26,000 |
Compare Phoenix with Other Leading Battery Brands in Pakistan
Before finalizing your purchase, explore how Phoenix compares with Pakistan’s top competitors:
- AGS Battery Price in Pakistan: Renowned for Japanese GS Yuasa technology, high build quality, and superior lead purity.
- Osaka Battery Price in Pakistan: The most budget-friendly tubular option with wide nationwide distributor availability.
- Exide Battery Price in Pakistan: Excellent high-discharge performance with legendary heavy antimony lead plates.
- Lithium Battery Price in Pakistan: Consider upgrading to LiFePO4 batteries for 10–15 years lifespan with zero maintenance.
- Solar Inverter Price in Pakistan: Check compatible hybrid solar inverters (1kVA to 6kVA) to match your battery bank.
How to Extend Your Phoenix Battery Life (4–6 Years Lifespan Tips)
A major reason batteries in Pakistan fail within 18 to 24 months is improper maintenance and incorrect solar inverter charging voltages. By following these proven practices, you can easily extend your Phoenix battery’s working life to 4 or even 6 years:
Always top up exclusively with de-ionized distilled water. Tap water or filtered mineral water contains chlorides, iron, and heavy minerals that permanently poison the active lead plates and accelerate internal self-discharge.
Never drain your battery below 50% Depth of Discharge (DOD). Configure your inverter’s low battery cut-off voltage to 10.5 Volts (or 21V on 24V inverters). Deep discharge down to 9V causes irreversible lead sulphate crystallization.
Use a hydrometer once every two months to check specific gravity. At 100% full charge, gravity should read between 1.240 and 1.260. If gravity drops below 1.180 despite charging, your inverter charging current needs calibration.
White acidic powder on terminals introduces electrical resistance and causes terminal melting. Clean terminals with warm water and baking soda, dry thoroughly, and apply a thin coating of pure petroleum jelly (Vaseline). Never use automotive wheel grease.
Critical Safety Guidelines for Home UPS & Solar Batteries
⚠️ Lead-acid and tubular batteries release volatile hydrogen gas and contain corrosive sulphuric acid. Always follow these safety rules:
- Ventilated Area Only: Never install batteries inside closed, unventilated bedrooms, airtight cupboards, or under staircases without airflow. Explosive hydrogen gas builds up during charging and can ignite from a small electrical switch spark.
- Adequate DC Cable Sizing: Connect your inverter with minimum 16mm² to 25mm² pure copper cables with pressed copper lugs. Thin or loose wires heat up excessively under 80A+ loads and cause house fires.
- Eye & Skin Protection: When topping up battery electrolyte or checking water levels, wear protective glasses. Sulphuric acid causes severe skin and corneal chemical burns. Keep a bottle of clean tap water nearby to wash off splashes immediately.
- Keep Away from Flammable Substances: Maintain at least 3 feet distance between batteries and gas cylinders, cooking stoves, or generator exhaust pipes.
How to Identify Original vs Reconditioned Phoenix Batteries
Due to high demand and rising battery prices across Pakistan, counterfeit and reconditioned batteries are frequently sold in local markets. Before paying your dealer, perform these 3 essential checks:
- Check Manufacturing Date Code: Look at the code embossed directly into the plastic top cover. Never buy a dry uncharged battery that is older than 3 months, as plates undergo internal shelf-sulphation.
- Verify Terminal Lugs: New factory-fresh terminals are smooth, silvery-grey, and completely free of screwdriver dents, clamping scratches, or acid pitting marks.
- Factory Warranty Card with Serial Match: Ensure the unique engraved serial number on the battery case matches the printed serial on the manufacturer’s official warranty card. Always demand a computerized sales invoice with the dealer’s stamp.
Frequently Asked Questions About Phoenix Battery
What is the price of Phoenix TX 1800 tubular battery in Pakistan?
The market price of a brand new Phoenix TX 1800 (165 Ah) tubular battery ranges between Rs. 46,000 and Rs. 48,500. If you trade in your old scrap battery, you can get an exchange rebate of Rs. 6,000 to 8,000.
Which Phoenix battery is best for a 1kVA / 1.5kVA domestic UPS?
For a standard 1kVA to 1.5kVA domestic UPS, Phoenix TX 1800 (165 Ah) or Phoenix TX 2000 (185 Ah) is the best option. They provide 6 to 8 hours of backup and have a service life of 4 to 5 years.
What is the warranty period for Phoenix tubular batteries?
Phoenix TX Series tubular batteries come with a 1-year (12-month) official free replacement warranty backed by Century Paper & Board Mills service centers nationwide.
What is the difference between Phoenix TX (Tubular) and UGS (Lead-Acid)?
Phoenix TX tubular batteries feature heavy cylindrical positive plates designed for deep cycle solar discharge (80% DOD) and last 4–5 years. UGS batteries use flat lead plates best suited for light domestic UPS backup with a typical lifespan of 2–3 years.
How much scrap rebate can I get for an old battery when buying Phoenix?
Authorized battery dealers offer an exchange value of Rs. 420 to Rs. 460 per kilogram of your dead lead-acid battery. For a medium 25 kg UPS battery, this translates to an immediate discount of Rs. 6,000 to Rs. 9,500.
How often should I top up distilled water in a Phoenix tubular battery?
Under normal hybrid solar cycling, water top-up is needed once every 2 to 3 months. Check the red level indicators on the vent plugs and never allow the liquid level to drop below the white ceramic marker.
