VFD Inverter Price in Pakistan: The current market price of industrial and solar VFD inverters in Pakistan ranges between Rs. 31,000 for small 7–11kW models and goes up to Rs. 3,250,000 for large 1000kW heavy-duty industrial cabinet systems. These drives are widely used in agricultural submersible water pumps, industrial electric motors, compressors, and CNC machinery to control motor speed and cut electricity consumption by 30% to 60%.
Most available models in Pakistan belong to the CHF-100 series from INVT, offering a 1-year replacement warranty. Prices mainly depend on kW rating, IGBT ampere capacity, copper build quality, and whether the unit is a standard compact card or an industrial cabinet drive.
📊 Current INVT VFD Price in Pakistan (CHF-100 Series)
Rates surveyed across major electrical markets including Hall Road & Brandreth Road (Lahore), Denso Hall & Regal Chowk (Karachi), and Katchery Bazaar (Faisalabad):
| Power Range (kW) | Type / Build Quality | Price (PKR) |
|---|---|---|
| 7–11 kW | 680UF / 75A IGBT | Rs. 31,000 |
| 11–15 kW | 820UF / 100A IGBT | Rs. 33,000 |
| 15–18 kW | 1000UF / 110A IGBT | Rs. 35,000 |
| 18–22 kW | Full Capacity | Rs. 60,000 |
| 18–22 kW | China Compact Card | Rs. 72,000 |
| 22–30 kW | Full Capacity | Rs. 64,000 |
| 22–30 kW | China Compact Card | Rs. 74,000 |
| 30–37 kW | Full Capacity | Rs. 72,000 |
| 30–37 kW | China Compact Card | Rs. 82,000 |
| 37–45 kW | Full Capacity | Rs. 98,000 |
| 37–45 kW | China Compact Card | Rs. 104,000 |
| 45–55 kW | Full Capacity | Rs. 110,000 |
| 55–75 kW | Full Capacity | Rs. 115,000 |
| 75–90 kW | Copper Full Capacity | Rs. 170,000 |
| 90–110 kW | Copper Full Capacity | Rs. 190,000 |
| 110–132 kW | Copper Full Capacity | Rs. 200,000 |
✔ All models are CHF-100 series • ✔ 1-Year Local Replacement Warranty
*Note: VFD rates taken from Pakistani + China local importers. Refurbished or checking-warranty units are available at 30–40% lower prices in Bilal Gunj Lahore.
🔍 China Compact Card vs Full Capacity vs Copper Full Capacity
Drives differ significantly in component grade, heat dissipation, and continuous operating life:
| Feature | China Compact Card | Full Capacity | Copper Full Capacity |
|---|---|---|---|
| Price Level | Budget friendly | Mid-range | Premium |
| Internal Components | Standard PCB & IGBT | Upgraded components | High-grade copper components |
| Load Handling | Light to medium load | Medium to heavy load | Heavy industrial load |
| Heat Handling | Moderate | Better cooling | Excellent heat control |
| Performance Stability | Basic | Stable | Very stable & smooth |
| Best For | Small motors, light industry | General factory use | Continuous heavy-duty motors |
| Lifespan | Normal | Long | Longest |
🏗️ INVT Cabinet VFD Price in Pakistan (CNC Copper Sets)
All cabinet units are original China CNC copper sets designed for large factories, water utility pump stations, and heavy industrial machinery:
| Power Range (kW) | Price (PKR) |
|---|---|
| 132–160 kW Cabinet VFD | Rs. 450,000 |
| 160–185 kW Cabinet VFD | Rs. 530,000 |
| 185–200 kW Cabinet VFD | Rs. 570,000 |
| 200–220 kW Cabinet VFD | Rs. 730,000 |
| 220–250 kW Cabinet VFD | Rs. 840,000 |
| 250–280 kW Cabinet VFD | Rs. 890,000 |
| 280–315 kW Cabinet VFD | Rs. 930,000 |
| 315–350 kW Cabinet VFD | Rs. 1,100,000 |
| 350–400 kW Cabinet VFD | Rs. 1,200,000 |
| 400–500 kW Cabinet VFD | Rs. 1,390,000 |
| 500–600 kW Cabinet VFD | Rs. 1,750,000 |
| 600–800 kW Cabinet VFD | Rs. 2,250,000 |
| 800–1000 kW Cabinet VFD | Rs. 2,750,000 |
| 1000 kW Heavy Duty Cabinet VFD | Rs. 3,250,000 |
Select your Tubewell Motor Horsepower (HP) / Delivery Pipe Size, bore depth type, and Solar Plate Wattage (550W, 585W, 610W, or 700W). This calculator computes your exact Recommended INVT VFD Rating (with 1-grade starting surge margin), Total Solar Plates Needed, Series × Parallel String Wiring Plan, Live MPPT Voltage ($V_{mp}$ / $V_{oc}$), and Total Tubewell Cost:
🚜 Solar Tubewell VFD Sizing Guide (Motor HP vs Solar Panels)
Agricultural solar tubewell setups require a VFD rated 20% to 30% higher than the motor's nominal HP to safely handle starting torque and deep-bore water lifting:
| Motor Size | Recommended VFD | Solar Panels (585W) | VFD Cost |
|---|---|---|---|
| 7.5 HP Motor | 7.5 kW / 11 kW Dual | 14 – 16 Panels | Rs. 32,000 |
| 10 HP Motor | 11 kW VFD Drive | 18 – 20 Panels | Rs. 38,000 |
| 15 HP Motor | 15 kW VFD Drive | 24 – 28 Panels | Rs. 52,000 |
| 20 HP Motor | 18.5 kW / 22 kW | 32 – 36 Panels | Rs. 68,000 |
| 25–30 HP Motor | 30 kW / 37 kW | 44 – 52 Panels | Rs. 98,000 |
To budget your complete solar array, check our daily updated Solar Panel Price in Pakistan tracker, and compare hybrid residential units in our Solar Inverter Price Guide.
📈 6-Month VFD Price Trend in Pakistan
Historical price movement for average mid-range VFD drives (11–15kW):
| Month | Average Mid-Range (11–15kW) |
|---|---|
| Sep 2025 | Rs. 68,000 |
| Oct 2025 | Rs. 55,000 |
| Nov 2025 | Rs. 50,000 |
| Dec 2025 | Rs. 45,000 |
| Jan 2026 | Rs. 38,000 |
| Feb 2026 | Rs. 33,000 |
Trend Insight: Prices increased during import shipment delays and dollar fluctuations but have stabilized significantly due to direct container consignments.
🏙️ City-Wise VFD Price Variation
| City | Market Condition |
|---|---|
| Lahore | Base wholesale market (Hall Road / Brandreth Road) |
| Karachi | Slightly higher due to port handling & transport |
| Faisalabad | High textile demand impact |
| Gujranwala | Heavy industrial motor & pump demand |
⚙️ What is a VFD Inverter?
A VFD (Variable Frequency Drive) inverter controls the speed of an AC motor by adjusting frequency and voltage. Instead of running motors at full speed all the time, a VFD allows speed control based on load requirement.
Key Industrial Benefits:
- 30–60% Electricity Savings: Motor consumes power proportional to speed rather than fixed max load.
- Soft Motor Starting: No heavy inrush current shock; protects windings from burnouts.
- Longer Motor Life: Eliminates mechanical stress on belts, gears, and pump impellers.
- Reduced Mechanical Wear: Minimizes maintenance down-time across factory lines.
- Precise Speed Control: Direct digital adjustment of RPM for accurate flow and pressure.
In Pakistan’s industrial sector, VFDs are commonly used in textile mills, water pumping stations, elevators, compressors, and CNC machinery.
Why VFD Prices Change in Pakistan?
- US Dollar exchange rate against PKR
- Import container freight and clearance costs
- Global copper and silicon IGBT price fluctuations
- Seasonal agricultural tubewell demand (paddy and cotton sowing seasons)
- Custom import tariffs and regulatory duties
🛒 VFD Buying Guide: Check These Before Purchasing
- Motor kW Rating: Confirm the exact motor nameplate rating before sizing the drive.
- Ampere Capacity: VFD continuous ampere rating must always exceed the motor's full-load ampere (FLA).
- Copper Build Quality: For continuous industrial loads, always prefer Copper Full Capacity drives.
- Compact Card Limitations: Compact card versions are only suitable for light to medium intermittent duty.
- Warranty Verification: Ensure a 1-year replacement warranty card from an authorized local distributor.
⚠️ Essential Safety, Parameter Tuning & Installation Guidelines
- Hire a Qualified Industrial Technician: Never attempt live wiring without training—the large DC bus capacitors (680µF–1000µF) inside a VFD retain lethal 500V–750V DC charge for several minutes even after disconnecting solar panels or AC mains.
- Configure Minimum Frequency Cut-Off (25Hz–30Hz Rule): When running a water-cooled submersible borehole pump on solar, set the lower frequency sleep threshold so the motor shuts down cleanly during heavy evening clouds rather than spinning at 10Hz–15Hz, where water stops lifting and the motor windings overheat.
- Keep PV String Open-Circuit Voltage ($V_{oc}$) Below 750V DC: A 380V three-phase INVT CHF100A / GD100-PV drive operates ideally with a solar string MPPT voltage between 520V and 620V DC (typically 12 to 15 N-Type 585W panels in series). Connecting 18+ panels in a single series string exceeds the 800V DC capacitor limit on cold winter mornings and blows the IGBT module instantly.
- Install Dedicated Earth Grounding & DC Surge Arresters: Connect the VFD chassis PE terminal to a dedicated copper earthing pit and install a 1000V DC Breaker + SPD surge protector between the solar stand and the inverter.
- Clean Cooling Fans Monthly: Agricultural tubewell rooms and flour mills (Atta Chakkis) accumulate heavy dust and chaff. Blow out the aluminum heatsink fins and cooling fan every month so the IGBT module does not trip on
OH1 / OH2(Overheat) errors during peak summer afternoons.
📹 Practical INVT VFD Parameter Setting Video Guide
Configuring motor nameplate parameters (P0/P2 group), solar MPPT voltage tracking, and fault protection codes (such as OC1 over-current, OU1 over-voltage, and SPO output phase loss) requires step-by-step keypad calibration. Watch this practical field tutorial for complete INVT setup instructions:
More error fixing videos are available on Guljan Bugti Channel covering basic setup, motor kW configuration, frequency setting, acceleration/deceleration timing, and common error codes troubleshooting.
What is the starting price of INVT VFD in Pakistan?
Entry-level 7–11kW INVT VFD starts from approximately Rs. 31,000 for standard 680UF / 75A IGBT models.
Which INVT series is available in Pakistan?
Most industrial and solar models available in Pakistan are CHF-100 and GD100-PV series, backed by a 1-year local replacement warranty.
Are cabinet VFDs made in China?
Yes, heavy industrial cabinet VFDs are original China CNC copper sets ranging from 132kW to 1000kW.
Which VFD type is best for heavy load motors?
Copper full capacity versions and industrial cabinet drives are recommended for heavy industrial machinery, flour mills, and continuous deep tubewells.
Where are wholesale VFD markets located in Pakistan?
The major wholesale markets are Hall Road & Brandreth Road in Lahore, Denso Hall in Karachi, and Katchery Bazaar in Faisalabad.
